6KW 10KW PV Solar Inverter (AN-PVI )

Name: 6KW 10KW PV Solar Inverter (AN-PVI )
Brand: Guangzhou Anern Energy Technology Co., Ltd.
Availability: InStock

The AN-PVI series pure solar PV inverters are high-efficiency, grid-tied PV inverters designed for solar power systems without battery storage. They are cost-effective and efficient for applications where energy storage is not needed. This pv inverter supports direct connection to utility grids or diesel generators and features advanced MPPT tracking. The PVI-6000 model has dual MPPT inputs, while the PVI-10000 model has three MPPT inputs.

Get Free Quote

Key Features of 6KW 10KW PV Inverter

◆ Pure sine wave inverter

◆ Configurable input voltage range for home appliances and personal computers viaLCD setting

◆ Combind to the grid based on applications via LCD setting

◆ Compatible to mains voltage

◆ Auto restart while AC is recovering

◆ Overload/ Over temperature/ short circuit protection

◆ Cold start function

◆ Dual mppt at 4KW and 6KW,three mppt at 10KW and 15KW

◆ Can Running 1.5P motor with 4KW,3P motor with 6KW, 1.5P+3P motor with 10KW,3P+3P motor with 15KW

◆ Full load work with solar only

Specification of 6KW 10KW Solar PV Inverter

Item. No.	AN-PVI-6000	AN-PVI-10000
Phase	1-phase in /1-phase out
Maximum PV Input Power	4500W*2(9000W)	4500W*2(13500W)
Rated Output Power	6000W	10000W
MPPT Voltage Range	60-450Vdc
Number of MPPT Trackers /Maximum Input Current	2/18A	3/18A
Nominal Output Voltage	220/230/240VAC
Acceptable Input Voltage Range	184-264.5VAC or 195.5-253VAC or 184-264.4VAC(Selectable)
Frequency Range	50 Hz/60 Hz(Auto sensing)
Maximum AC Input Current	40A	50A
DimensionDxWxH(mm)	360x278x106	360x310x107
